P. 2
特點 FEATURES
採用一體成型之浮筒，填充PU， Adopt an integrally formed float, filled with PU, It can
可使用於惡劣環境，壽命長。 be used in harsh environments and has a long product life.
The height of the suction port can be adjusted according
可依液面水位調整吸入口高度。 to the liquid level.
可依現場需求選用不同葉型之泵浦。 Pumps with different impller type can be selected according
安裝容易。 to site requirements.
Easy to install.
用途 APPLICATIONS
The supernatant liquid and surface water are pumped out.
上澄液、表面水抽取。 Suspended solids, scum, and oil floating on water
水面懸浮物、浮渣、浮油抽取。
型號說明 PRODUCT NUMBER DESCRIPTION
SSPS/SCSS/SCPC
1 SSPS-60.75-50
出口口徑 OUTLET DAIMETER(mm)
額定動力 RATED POWER(kW)
頻率 FREQUENCY (Hz)
泵浦型號 PUMP TYPE
浮筒式 FLOATING
性能規格表 SPECIFICATIONS
相數
型號 動力 極數 葉輪型式 通過粒徑 揚程範圍 水量範圍
Kw Phase Pole mm M Lpm
SSPS-60.4-50 0.37 3 2 隱藏半開放 RECESS 16 >=1.5 <=180
SSPS-60.75 -50 0.75 3 2 隱藏半開放 RECESS 16 >=1.5 <=260
SCPC-60.75 -50 0.75 3 2 不阻塞型 NON-CLOG 25 >=1.5 <=400
隱藏式不阻塞型
SCSS-60.75-50 0.75 3 2 38 >=1.5 <=250
VORTEX
外型尺寸 DIMENSIONS
cmsa-pumps.com
