特點 FEATURES

            機組面積小，不佔場所                                         Small unit area.
     CVS
            出水管與軸心保護管分開，柱管內流體                                  The outlet pipe is separated from the shaft protection pipe,
                                                               The fluid in the column tube cannot rise to the bottom plate,
            無法上升至底盤，揚液無洩漏之虞。                                   and there is no risk of liquid leakage
            構造簡單，堅固耐用。                                         Simple structure, strong and durable
            泵殼及葉輪深入水中，無需呼水裝置。                                  Pump casing and impeller are deep into the water
                                                               without priming device
            採半開放式葉輪，可適用於輸送各體流體。                                It adopts semi-open impeller, which is suitable for a wide range
                                                               of liquids.

            用途 APPLICATIONS

            污水、清水或黏性流體抽送。                                      Sewage, clean water or viscous fluid pumping.
            腐蝕性流體(如醋酸、酸鹼性溶液)等。                                 Corrosive fluids (such as acetic acid, acid and
                                                               alkaline solutions), etc.
            非常溫液體(如液化氮、硫磺等)。                                   Non-normal temperature liquids
            揮發性或危險性液體(如汽油..等碳水化合物)                             (such as liquefied nitrogen, sulfur, etc.).
            的抽送。                                               Pumping of volatile or dangerous liquids
                                                               (such as gasoline or carbohydrates, etc.). .
      1

            構造STRUCTURE

            葉輪採半開放型式，附有背葉，有效降低軸                                The impeller adopts a semi-open type with backward blades
            向推力。                                                to effectively reduce the axial thrust.
                                                               The pump casing adopts a centrifugal scroll design,
            泵殼採離心渦卷設計，無填料涵裝置，其與                                no filler culvert device, and a supporting bearing device is
            柱管之間設支撐軸承裝置。                                       set between it and the column tube.
            吸入蓋處設濾網,防止異物吸入。                                    A filter is installed at the suction cover to prevent the
                                                               inhalation of foreign matter.
            軸心採不銹鋼材料經精密加工及表面硬化處                                The shaft center is made of stainless steel and has been
            理，耐磨耗及腐蝕以延長使用壽命。                                   precision finishing and surface hardened, which is
            軸承:                                                wear-resistant and corroded to extend its service life.
                                                               Bearing:
            馬達側：使用重負荷推力軸承，加大設計壽                                Motor side: Heavy-duty thrust bearings are used to
            命。使用滑脂潤滑(Grease)潤滑。                                increase the product life. Use grease lubrication .
            其他：為特殊合金銅製品耐用性佳，使用機                                Others: Alloy copper products have good durability
                                                               and use engine oil for lubrication. .
            油潤滑。.                                              Shaft sealing device:
            軸封裝置                                               Standard type: High-grade mechanical shaft seal is adopted.
            標準型：採用高級品之機械軸封。                                    Special type: use packing style.
                                                               (Some bearings use carbon products that do not require lubricants)
            特殊型：使用填料方式。                                        Column pipes and water delivery pipes can be made of steel
            (部分軸承使用不必潤滑劑之碳精製品)                                 pipes of different materials according to the nature of the fluid,
            柱管及送水管可隨流體性質使用不同材質之                                and the products can be completed by welding.
                                                               The baseplate is made of rectangular steel plate (or cast iron)
            鋼管，採焊接方式可完成製品。                                     products. .
            機座採長方形之構造用鋼板(或鑄鐵)製品。


            型號說明 PRODUCT NUMBER DESCRIPTION






                                                                     口徑               OUTLET DAIMETER(mm)

                                                                     額定動力             RATED POWER(kW)
                                                                     頻率               Hertz：6:60Hz；5：50Hz

                                                                     標準型式CVS          PUMP TYPE
